Precision CNC Milling

The key to the victory of plastic CNC milling lies in the correct selection of materials. The processability of different plastics varies greatly: soft plastics are prone to sticking to knives, brittle plastics are prone to edge breakage, and semi crystalline plastics are prone to warping. Choosing the wrong information not only leads to part deformation, surface tearing, and size deviation, but also causes serious waste of time and cost.

We are not just a processing factory, but also your data engineering consultant, assisting you in avoiding risks from the source.

PEEK	Temperature resistance up to 250 ° C, with implant grade biocompatibility. The processing difficulty lies in the high cost and the need for anti-static treatment. We use low-temperature cutting and anti-static fixtures, which are commonly used for PEEK CNC milling medical implants and aviation structural components.
Delrin (POM)	Excellent dimensional stability and low friction coefficient. Moisture absorption shrinkage and internal stress are the main difficulties. We have undergone pre conditioning treatment and residual stress annealing to effectively ensure that Delrin CNC machining is used for gears, bearings, and fine sliders.
UHMWPE	Extremely high wear resistance and self smoothing performance. Soft and easy to stick knives, we use sharp cutting tools combined with high-speed shallow cutting strategies, suitable for joint pads and food delivery parts (UHMWPE machining).
Polycarbonate (PC)	High transparency and high impact strength. Easy to crack under stress, we use stress free clamps and diamond cutting tools, suitable optical lens holders and protective covers.
Acrylic (PMMA)	Optical grade transparent, easy to process but highly brittle. We develop specialized cutting paths and polishing processes, commonly used for acrylic CNC milling optical tubes and display components.
PTFE	Extremely low friction coefficient and excellent chemical corrosion resistance. Extremely soft and prone to dimensional creep, we have completed fine machining through support clamping and cooling control for sealing components and chemical valve seats.
Nylon (PA6/PA66)	High strength and wear resistance. Moisture absorption deformation and burrs are challenges, and we have undergone moisture conditioning pre-treatment and sharp tool treatment, making it suitable for constructing brackets and transmission components.
Ultem (PEI)	High temperature, high strength, and flame retardant. Due to high internal stress, it is prone to cracking. We use annealing pretreatment and light cutting technology for aviation interiors and electrical insulation components.
HDPE	Chemical resistant and food grade. Soft and easily deformable, we prioritize using vacuum clamping and cooling strategies for food containers and chemical tanks.



Data selection decision-making service



We provide free information consultation services, and our engineers will recommend the best information based on the retirement environment, temperature range, chemical contact medium, and certification requirements of the parts.



We also provide cost optimization and import substitution plans, and can send processing samples of the main materials for you to personally confirm the touch, color, and hardness.



The victory of engineering plastic CNC parts starts with selecting the right materials.



The biggest technical challenge of plastic CNC milling is deformation and warping. Plastic residual internal stress, extremely low thermal conductivity, clamping pressure, moisture absorption shrinkage, and material anisotropy can all easily lead to dimensional loss of control after processing.

Pre machining annealing is used for materials such as POM, PC, Ultem, PEEK, etc. It releases freezing stress according to a specific temperature curve before processing, which can reduce subsequent deformation by 60-80%.

Moisture conditioning is used to process moisture absorbing materials such as Nylon and POM by balancing the moisture content in a controlled humidity environment, completely eliminating the size drift caused by moisture absorption.

Progressive Cutting Strategy: rough machining → stress relief parking for 24 hours → semi precision machining → precision machining, gradually releasing stress, and finally achieving high dimensional stability.

Low temperature cutting+cold air cutting uses DLC coated diamond cutting tools combined with cold air cooling to control the cutting zone temperature below 35 ° C, preventing stress cracking caused by traditional cutting fluids on PC and PMMA.

The Stress Free Clamping design utilizes a vacuum adsorption platform, specialized soft claws, and thin-walled support wax to achieve average force distribution and minimize clamping deformation through stress free plastic machining.



Typical case:





A customer's PC transparent optical shell (wall thickness 1.2mm), previously both suppliers showed severe warping. We adopt annealing+air cooling+vacuum adsorption+step-by-step processing, and the final flatness is controlled at 0.05mm (better than the customer's requested 0.08mm), with no atomization in transparency. The batch Cpk reaches 1.52, and we have obtained the customer's exemption from inspection and storage qualification.



Through systematic plastic CNC deformation control, we have achieved zero compromise in precision plastic machining.

The appearance requirements for plastic parts are often higher than those for metal parts. Blade patterns are more easily visible, and transparent parts require cleanliness close to optical grade. Color divergence and corner treatment directly affect the final quality.





Mechanical Polishing: Step by step sandpaper and polishing paste, up to Ra 0.1 μ m mirror level, especially suitable for PC and PMMA optical parts with clear plastic CNC machining.



Flame Polishing: For acrylic PMMA, quickly restore high optical grade plastic milling.





Beam Blasting: Creating an average matte texture, effectively masking fine knife marks, and suitable for plastic surface finish CNC construction.





Coating/Coating: Provide EMI shielding conductive coatings, wear-resistant coatings, or customized colors to meet the requirements of electronic device casings.

In terms of functional accuracy, we can achieve precise matching of aperture H7 and shaft diameter h6. The plastic threads use specialized cutting parameters to avoid misalignment and tooth breakage, and support functional tests such as airtightness, assembly fit, and pressure resistance.

Comprehensive case:

The transparent shell of medical equipment PC combines the requirements of appearance mirror and fine positioning hole function, and finally achieves a Ra 0.15 μ m mirror effect with a positioning hole tolerance of ± 0.03mm. Customers can directly enter the warehouse without inspection.

 Plastic CNC milling has been widely used in multiple high demand industries:

Medical & Life Sciences

Typical parts: surgical instrument grip, diagnostic equipment housing, microfluidic chip, PEEK implant components.

Key requirements: biocompatibility, cleanroom processing, and sterilization capability.



Our solution: Medical plastic machining using PEEK, UHMWPE precision machining and providing clean packaging.

Aerospace & Defense

Typical parts: cabin interior parts, insulation brackets, radar fairing (PTFE/Ultem).

Key requirements: flame retardant, lightweight, AS9100 compliance.



Our solution: Ultem and PEEK precision milling and providing complete compliance documents (aerospace plastic components).

Electronics & Semiconductor

Typical parts: wafer carrier (PEEK/POM), connector insulator, test fixture.

Key requirements: anti-static, dimensional stability, and chemical cleaning resistance.



Our solution: Electronic plastic CNC parts use anti-static materials and precision tolerance control.

Food & Beverage

Typical parts: food grade conveyor belt assembly (UHMWPE), filling machine slider, cutting guide plate.

Key requirements: FDA compliant food contact, resistant to cleaning agents, non-toxic and odorless.



Our solution: FDA grade UHMWPE and HDPE precision processing.

Research & Prototyping

Typical parts: laboratory fixtures, fluid channel models, functional prototypes.

Key requirements: fast delivery, material diversity, and flexibility in small batches.



Our plan: minimum order of 1 piece, 7-day lead time, 20+material options (custom plastic parts manufacturer).

Industrial & Automation

Typical parts: guide rail slider (POM), cam follower, insulation gasket (PTFE).

Key requirements: Wear resistance, dimensional stability, low friction.



Our solution: POM, UHMWPE, PTFE precision milling.

We chose plastic CNC milling services because we truly understand the common pain points of plastic processing and provide processing plans that far exceed industry uniformity.

Special technical advantages

Exclusive plastic processing workshop (completely separated from metal parts to avoid pollution)



Plastic specific tool library (DLC coated, diamond coated, high rake angle tools)



Complete annealing and humidity control equipment (self built temperature controlled annealing furnace+constant humidity storage room)



Constant temperature processing environment (workshop temperature 22 ± 1 ° C)

Professional team support

A data engineer with 12 years of experience, specializing in plastic selection consulting; Process engineers focus on deformation control; DFM engineers can issue a manufacturability report within 48 hours.

Real customer cases

A medical equipment manufacturer in Europe has purchased 5000 pieces of PEEK fine parts for three consecutive years with zero rework.

Semiconductor wafer fixture supply, tolerance ± 0.02mm, 100% CMM inspection qualified.

Certification qualifications: ISO 9001:2015, ISO 13485 (Medical), FDA Food Contact Compliance RoHS. As a reliable plastic machining supplier, we strive to provide every customer with the most professional precision plastic machining services.
