Core Advantages

PEEK (polyetheretherketone) is one of the highest-performing engineering plastics, valued for thermal stability, chemical resistance, mechanical strength, and biocompatibility. Our Precision PEEK Milling Services deliver tight-tolerance, high-quality components for demanding industries.

Key advantages:

Low-contamination processing:

Dedicated clean machining environment aligned with ISO 13485 and AS9100 expectations, helping keep parts free of oil, metal debris, and environmental contaminants - critical for medical and semiconductor applications.

Strong dimensional stability:

Machining strategies that minimize thermal deformation and internal stress, supporting long-term dimensional accuracy in complex geometries.

Cost-aware programming:

Intelligent CAM programming, optimized toolpaths, and careful tool selection reduce material waste of high-cost PEEK stock - helping keep project costs under control.

Backed by an established quality management system and years of experience in high-performance plastics, we serve medical-device manufacturers and aerospace companies worldwide.

Material Characteristics

We machine a full range of PEEK grades to meet diverse application requirements:

Virgin PEEK:

unfilled, highest purity, balanced mechanical properties.

Glass-filled PEEK:

enhanced stiffness and dimensional stability.

Carbon-filled PEEK:

higher strength, rigidity, and wear resistance for heavy-duty applications.

Medical-grade PEEK (implantable):

USP Class VI and ISO 10993-tested grades for long-term human-implant applications.

Key thermal and mechanical properties of PEEK:

Glass transition temperature (Tg) ~143 °C; melting point (Tm) ~343 °C

Continuous service temperature ~250 °C; short-term excursions up to ~300 °C

Excellent chemical resistance to most solvents and aggressive media

Strong mechanical strength, fatigue resistance, and toughness

Good wear resistance, low friction, and excellent electrical insulation

Machining Capabilities

Our CNC machining of PEEK is engineered for ultra-precision and repeatability:

Equipment:

3-, 4-, and 5-axis CNC milling centers capable of producing complex surfaces, deep cavities, and tight-tolerance features.

Tolerance capability:

General ±0.05 mm; ±0.02 mm achievable on critical dimensions; ±0.01 mm on selected features supported by post-machining grinding/lapping.

Post-processing:

Professional deburring, polishing, high-gloss finishing, and stress-relief annealing for optimal surface quality and long-term dimensional stability.

Surface finish:

Ra down to 0.4 μm typical; finer finishes (≤ Ra 0.2 μm) available with dedicated polishing on appropriate features.

From rapid prototyping through small-to-medium-batch production, we cover the full range of precision PEEK parts.

Challenges & Solutions

PEEK presents specific machining challenges. Our process knowledge addresses each one:

Challenge 1 - Internal stress & warping

Solution: multi-stage annealing - annealing the stock before rough machining and again after semi-finishing - to relieve internal stresses and prevent distortion or cracking during or after machining.

Challenge 2 - Coolant contamination

Solution: for medical and semiconductor-grade parts, we use only deionized water or specially formulated low-residue coolants, eliminating the contamination risk associated with conventional cutting fluids.

Challenge 3 - Tool wear on filled grades

Solution: high-performance PCD (polycrystalline diamond) tooling combined with optimized cutting parameters maintains surface finish, dimensional accuracy, and tool life when machining abrasive carbon- and glass-filled grades.

Application Scenarios

Our Precision PEEK Milling Services serve critical applications across high-performance industries:

Medical devices:

implantable components, spinal-fusion cages, surgical instrument handles, and precision positioning parts requiring biocompatibility and tight tolerances.

Aerospace:

thermal shields, high-strength fasteners, aviation connectors, and lightweight structural components that withstand extreme temperatures and mechanical loads.

Semiconductor equipment:

wafer carriers, vacuum-chamber components, precision stages, and contamination-sensitive parts.

FAQ

Q1: Why is annealing important for PEEK milling?

Annealing is a critical step in PEEK machining. It relieves internal stresses introduced during cutting, preventing warping, distortion, and cracking that may otherwise appear during storage or in service. Proper annealing supports strong dimensional stability and long-term performance.

Q2: Can you achieve a mirror finish on milled PEEK parts?

Yes. Through dedicated polishing, high-gloss surface finishes (Ra ≤0.2 μm) are achievable on appropriate features for optical, medical, and premium aesthetic applications.

Q3: How do you handle medical-grade PEEK traceability?

We maintain full material traceability for medical-grade PEEK. From raw-material batch records and processing documentation to final shipment, every part is accompanied by complete quality records and Certificates of Conformance, supporting compliance with ISO 13485 and customer regulatory requirements.

Q4: Do you support small-batch or prototype PEEK machining?

Yes. We specialize in rapid prototyping and low-to-medium-volume production, making us a strong partner for product development, engineering validation, and initial production runs.
